Cat CL210 Load Haul Dump (10 Ton LHD)

The Cat CL210 is a high-performance Load Haul Dump designed for underground mining and material transportation. With a 10-ton capacity and compact structure, it ensures reliable performance in narrow tunnels and challenging mining conditions.

Key Specifications

• Payload: 10 tons

• Width: 2300 mm

• Steering angle: 45°

• Dump angle: 8°

• Engine: CAT diesel, high-torque performance

• Transmission: Hydromechanical system, low maintenance



  Cat CL210 Load Haul Dump side view

  Technical Features & Advantages

  • Advanced RAS quick-change system

  • Multiple attachments for versatile operations

  • Low operating cost and long lifecycle

  • Easy maintenance with accessible components

  • Proven reliability under harsh mining environments

    Applications

    CL210 Load Haul Dump is suitable for:

    • Underground metal and coal mines

    • Material transport and haulage

    • Roof support logistics

    • Towing and utility operations

      Attachments & Spare Parts

      Ningdong Group provides original and OEM spare parts for the CL210 LHD, including:

      • Axles and hydraulic pumps

      • RAS attachment kits

      • Transmission and braking systems

      • Electrical and control modules

      ✅ Internal link example:
      “See more CL210 Spare Parts”

      Why Choose Ningdong Group

      • Professional supplier for mining and tunneling equipment

      • Global sourcing of Cat CL210 components

      • Fast delivery & technical support

      • Multi-language service: English, Russian, Chinese

        FAQs

        Q1: What is the payload of the CL210?
        → The rated payload is 10 tons.

        Q2: Does Ningdong supply compatible parts for CL210?
        → Yes, we supply both genuine and high-quality replacement parts.

        Q3: What’s the difference between CL210 and CL215?
        → CL215 offers a slightly higher payload and engine power; CL210 is more compact for narrow tunnels.

        Contact Us for Inquiry

        Looking for CL210 LHD or parts?
        👉 Contact Ningdong Group
        We will provide technical datasheets, drawings, and competitive offers.

        Serial Number	Part Number	name	quantity
        	506223	Engine and mounting components	1
        1	506224	Engine 3126 230hp Explosion-proof Improved Version	1
        2	503663	Engine mount – front	1
        3	503664	Engine mount – rear driver’s side	1
        4	504544	Engine mount – Rear driver opposite side	1
        5	B165050221	Bolt, M16*50mm	8
        6	W11222	12mm washer	4
        7	W11622	16mm washer	8
        8	B121020321	Bolt 3/4UNC	6
        9	N121321	Nut 3/4UNC	6
        10	W21222	Washer 3/4	6
        11	505748	Remote oil pan drain bracket 1″ BSPT	1
        12	506480	Connector, 90° elbow 1″ convex	1
        13	504703	1/2″ Ball Valve BSP	1
        14	506481	Connector, pipe fitting 1″BSPT convex * 1 1/16JIC convex	1
        15	505827	Bell-shaped shell respirator mounting bracket	1
        16	504613	1″ Two-way ball valve	1
        17	506180	Breathing hose screw	1
        18	B061016221	Screw, 3/8″UNC*2″GR: Galvanized hexagonal head	2
        19	W20622	Washers, 3/8″ galvanized springs	2
        20	506483	Connector, 90° elbow 1 1/16 JIC swivel	1
        21	506484	Connector, 45° elbow 1 1/16 JIC swivel	1
        22	506485	3/4″ UNO connector straight * 1 1/16 JIC connector	1
        23	508736	Vent	1
        24	509381	3/4″ UNO convex plug – Improved	1
        25	503662	Engine CAT3126 230hp	1
        26	505779	Improved thermostat housing with lower height CAT3126	1
        27	503595	Aftercooler	1
        28	505781	Gasket Thermostat Housing	1
        29	505782	Gasket aftercooler	1
        30	504611	Fan belt	1
        31	504508	water jacket turbocharger	1
        32	506468	90° elbow 1 1/16″ JIC*3/4 hose end	1
        33	506469	O-ring	1
        34	506466	Tube	1
        35	506467	Oil meter	1
        36	B081012321	Screw, 1/2″UNC*1 1/2″GR:8 galvanized hexagonal head	4
        37	508191	Connector – behind the outlet	1
        38	505960	washer	1
        39	503469	Engine oil filter	1
        40	506604	Distillery filter (fine)	1
        41	506657	Fuel injector assembly	1
        42	506655	Exhaust manifold gasket	3
        43	506656	Turbocharger gasket kit	1
        44	506723	pump	1
        45	506654	rocker arm cover washer	1
        46	506653	Exhaust manifold	1
        47	506647	thermostat	1
        48	506646	Air compressor assembly	1
        49	506644	Air compressor liner kit	1
        50	506643	Oil pan gasket	1
        51	506641	Cylinder head gasket kit	1
        52	506640	Engine fuel pump assembly	1
        53	506639	manual fuel primary pump	1
        54	506638	Oil cooler gasket kit	1
        55	506637	Engine oil cooler	1
        56	506605	Flywheel ring gear	1
        57	506606	oil pan	1
        58	506607	Belt pulley tensioner assembly	1
        59	506608	Crankcase pulley	1
        60	506609	Water pump pulley	1
        61	506636	Oil Add Cap	1
        62	506649	Turbocharger assembly	1
        63	509768	O-ring pump	1
        64	509769	O-ring pump	1
        65	506565	turbocharger	1
        66	504508	water jacket turbocharger	1
        67	504015	Cover the fuel tank	1
        68	502721	washer	2
        69	504017	Fuel tank cap	1
        70	504016	Sealed fuel tank	1
        71	501534	Fuel cap	1
        72	503436	Primary fuel filter	1
        73	504849	Fuel isolation valve	1
        74	503910	fuel gauge	1
        75	504116	90° elbow connector 3/4 UNO convex * 9/16″ JIC convex	1
        76	504231	90° elbow connector 9/16JIC convex * 9/16″ UNO convex	1
        77	504190	45° elbow connector 1/4 BSPT * 9/16″ JIC convex	1
        78	504212	Connector diameter reduction 3/4″ BSPT convex * 1/2″ BSPT concave	1
        79	504162	Connector pipe fitting 1/2BSPT concave * 9/16″JIC convex	1
        80	504230	90° elbow connector 9/16 JIC convex * 9/16″ JIC convex	1
        81	504189	Connector pipe fitting 1/4BSPT convex * 9/16″ JIC concave rotary	1
        82	504700	support	1
        83	506471	XHLO connector convex adapter tube	1
        84	501539	fuel cooler	2
        85	504411	Cover the fuel tank	1
        86	B061010221	Screw, 3/8″ UNC*1 1/4″ GR:5 galvanized hex head	32
        87	W20612	Washer, 3/8″ flat galvanized	32
        88	506529	Fuel cooler base	1
        89	502075	T-shaped handle	1
        90	503689	build	1
        91	503690	Ontology	1
        92	503467	Filter cartridge (primary)	1
        93	503691	bowl	1
        94	503692	heat shield	1
        95	503693	one-way valve	1
        96	503694	Sealing repair kit	1
        97	506452	Air intake system components	1
        98	505088	Air filter assembly	1
        99	503597	Imported aftercooler	1
        100	500670	Explosion-proof grille air intake	1
        101	504632	Pipe clamp – hose, 4″	8
        102	503391	washer	1
        103	504642	Adapter tube – straight arch	3
        104	504385	Air filter support bracket	1
        105	506316	Pipe clamp assembly	1
        106	B061010221	Screw, 3/8″ UNC*1 1/4″ GR:5 galvanized hex head	4
        107	W20622	Washers, 3/8 galvanized springs	4
        108	505887	180° elbow	1
        109	506470	Intake pipe 1	1
        110	504641	Adapter pipe – 90° elbow	1
        111	506458	Intake pipe 2	1
        112	506590	Dust indicator	1
        113	506516	5″ air intake pre-filter with self-cleaning outlet	1
        114	507635	Adapter assembly	1
        115	505794	Air filter clamp	2
        116	505795	Cover – Air Filter	1
        117	505796	O-ring	1
        118	505089	Filter cartridge (secondary stage)	1
        119	505090	Filter cartridge (primary)	1
        120	503867	exhaust gas purifier	1
        121	503553	Downpipe	1
        122	503580	washer	1
        123	503581	washer	1
        124	B061010221	Screw, 3/8″ UNC*1 1/4″ GR:5 galvanized hex head	6
        125	W20622	Washers, 3/8 galvanized springs	6
        126	503560	Explosion-proof grille for air purifier	1
        127	504832	Lower pipe guard plate	1
        128	504833	plywood	1
        129	B105030221	Screw M10*30, length GR:8.8, galvanized hexagonal head.	4
        130	W13032	M30 flat galvanized gasket	4
        131	B081012221	Screw, 1/2″UNC*1 1/2″GR:5 galvanized hexagonal head	2
        132	W20812	Washer, 1/2″ flat galvanized	2
        133	503486	heat exchanger base	1
        134	500677	Particulate air filter	1
        135	503907	O-ring	1
        136	503557	cover plate	1
        137	503558	washer	1
        138	505965	Explosion-proof grille exhaust gas 200 CPI	1
        139	505802	Filter housing – New	1
        140	503563	Filter cover	1
        141	503566	Clip housing with threads	1
        142	503567	exhaust gas outlet	1
        143	503568	gasket	2
        144	503569	Spring seat	4
        145	503570	Fixed pin cover	1
        146	503571	Fixed pin explosion-proof grid	1
        147	503572	Locking plate	2
        148	503214	gasket	3
        149	503574	gasket	3
        150	503575	link	1
        151	503576	link	3
        152	503577	Elastic retaining ring	2
        153	503578	spring	1
        154	503579	spring	1
        155	500739	Gasket exhaust gas purifier	1
        156	502765	Gas Purifier with Liner Filter	1
        157	502764	Bypass valve	2
        158	N081223	Nut, 1/2″ UNC GR:5 galvanized heat exchanger nylon	7
        159	W20832	Washer, 1/2″ hard flat galvanized	15
        160	B081010443	1/2″ UNC*1 1/4″ Alloy Stainless Steel Socket Head Screw	12
        161	B061008443	3/8″ UNC*1 Alloy Stainless Steel Socket Head Screw	2
        162	W20261	Washers, 3/8 springs	8
        163	504019	Top flange	1
        164	504018	washer	1
        165	505804	handle	1
        166	505805	lever	1
        167	505806	gasket	1
        168	505807	Gasket grading	1
        169	503687	clip	1
        170	505332	pad	1
        171	506163	exhaust pipe	1
        172	B081012321	Screw, 1/2″UNC*1 1/2″GR:8 galvanized hexagonal head	8
        173	B061008321	Screw, 3/8″ UNC*1″ long GR:8 galvanized hexagonal head	24
        174	W20632	Washers, 3/8 hard flat galvanized	16
        175	DUD59-16	Connector, plug 1″ BSPT steel	1
        176	DUD59-08	Connector, plug 1/2″ BSPT steel	1
        177	DUD59-06	1/2″ BSPT screw plug	2
        178	500699	Master cylinder throttle	1
        179	500701	clip	1
        180	500700	Driven cylinder throttle	1
        181	506489	90° elbow connector 1/8 NPT convex * 7/16″ JIC convex	3
        182	500702	Storage chamber	1
        183	504501	Brake throttle	1
        184	B041026221	Screw, 1/4″UNC*3-1/4GR:5 galvanized hexagonal head”	1
        185	504466	Linkage end	1
        186	504502	Gasket throttle driven cylinder	1
        187	N041221	Nuts, 1/4″ UNC GR:5 galvanized standard	2
        188	B066020222	Screw M6*20, length GR:8.8, galvanized hexagonal head.	3
        189	504188	45° elbow connector 1/4 NPT * 7/16″ JIC convex	1
        190	B061006221	Screw, 3/8UNC*3/4GR:5 galvanized hexagonal head	2
        191	504564	Hose hydraulic 1/4*5500*7/16JIC	1
        192	504563	Hose hydraulic 1/4*3000*7/17JIC	1
        193	B051016221	Screw, 5/16″UNC*2″GR:5 galvanized hexagonal head	1
        194	W10622	Washer Spring M6	3
        195	N051223	Nut, 5/16″ UNC GR:5 galvanized nylon	1
        196	W20612	Washer, 3/8″ flat galvanized	2
        197	502378	Throttle return spring	1
        198	506425	Gasket throttle driven cylinder	2
        199	506438	Linkage end	1
        200	508661	Improved connector	1
        201	501676	Kit – Seal Repair – Throttle Master Cylinder	1
        202	501677	Kit – Seal Repair – Throttle Driven Cylinder	1
        203	503023	Engine cooling system components	1
        204	506726	Fan assembly -30° blades	1
        205	505298	Engine coolant radiator	1
        206	505326	heat exchanger radiator	1
        207	505679	Radiator external hinge	4
        208	503978	Fan adapter tube plug	1
        209	503993	Fan adapter tube	1
        210	504020	Nut plate	2
        211	504021	Base fan	1
        212	503904	motor fan	1
        213	504730	Expansion box	1
        214	500662	Cover assembly	1
        215	504648	2″ flexible radiator	1
        216	504646	Pipe clamps – hoses 56-59	20
        217	506114	Pipe hinge – assembly	1
        218	506115	Pipe hinge – assembly	1
        219	506119	Level gauge	1
        220	506116	Heat exchanger outlet – coolant pipe	1
        221	506117	The heat exchanger outlet coolant pipe is located under the engine.	1
        222	506118	Engine pump inlet – coolant pipe	1
        223	506123	Heat exchanger water pump outlet – coolant pipe	1
        224	506124	Heat exchanger water pump inlet – coolant pipe	1
        225	506125	Engine water pump inlet – coolant hose	1
        226	506126	coolant pipe	1
        227	506127	coolant pipe	1
        228	506139	heat exchanger inlet	1
        229	506140	heat exchanger outlet	1
        230	505734	Upper water tank with partition	1
        231	506527	washer	4
        232	506530	Water pump drive**	1
        233	503556	O-ring	2
        234	505594	Radiator cover	2
        235	506164	clip	8
        236	503670	Radiator support bar	1
        237	506528	Radiator shield	1
        238	506462	Radiator shield	2
        239	505677	Radiator hinge – O-ring	8
        240	505678	Radiator hinge bearing	4
        241	506006	pneumatic support	2
        242	506384	Pneumatic support fixed heat exchanger	1
        243	506383	Pneumatic strut for fixing engine coolant	1
        244	504834	Heat exchanger radiator hinge base	1
        245	504835	Engine coolant radiator hinge base	1
        246	505074	Fan anti-cavitation pressure relief block assembly**	1
        247	507836	connector	2
        248	506588	Pad flow switch	1
        249	504644	Fan blades	12
        250	503547	Fan hub	1
        251	B061008221	Screw, 3/8″UNC*1″GR:5 galvanized hexagonal head	6
        252	W20622	Washers, 3/8″ galvanized springs	6
        253	503307	Fixed pin	12
        254	501627	Water tank cap assembly on seat ring	1
        255	501628	Helicoil inserts screws onto the water tank cap assembly.	1
        256	501629	Spring washer on water tank cap assembly	1
        257	501630	Gasket on water tank cap assembly	1
        258	505811	Pump coolant heat exchanger**	1
        259	505886	coupling	1
        260	505883	Pump to hydraulic motor bracket	1
        261	503901	Mounting bracket	1
        262	505116	Support pump	1
        263	505882	5cc/rpm piston motor	1
        264	505968	coupling	1
        265	503840	casing	1
        266	506111	Hydraulic water pump with coupling protective cover	1
        267	B041004221	Screw, 1/4″UNC*1/2″GR:5 galvanized hexagonal head	1
        268	506682	elbow	1
        269	506683	Pipe fittings	1
        270	506684	hose connector	1
        271	506681	hose clamp	1
        272	506685	hose	1
        273	504454	safety valve	1
        274	504846	Priority flow control valve and body	1
        275	503900	pump	1
        276	506486	45° elbow connector 1/4″ BSPT convex * 7/16 JIC convex	1
        277	506463	outlet heat exchanger water pump	1
        278	509857	Water pump model 2	1
        279	509803	Screw – (M10*1.5*90)	4
        280	509768	O-ring	1
        281	509802	O-ring	1
        	504454**	Safety valve**
        282	502099	Safety Valve – Cylinder (Sealing Kit 507809)	1
        283	504455	Safety valve – body	1
        	505074**	Fan anti-cavitation pressure relief block assembly**
        284	504842	Pressure safety valve cylinder	1
        285	504843	Anti-cavitation check valve cylinder	1
        286	504841	Test point connector	1
        287		Section 3: Gearbox
        288	503025	Engine drive components	1
        289	503979	clock case	1
        290	503980	End cap	1
        291	503981	axis	1
        292	503982	bearings	2
        293	503983	gasket	1
        294	503984	bearing housing	1
        295	503985	end fork	1
        296	500708	Nut	1
        297	B061008221	Screw, 3/8UNC*1GR:5 galvanized hexagonal head	6
        298	505894	Fluororubber seals	2
        299	B071010211	Screw, 6/17UNC*1-1/4GR:5B Hexagonal head	12
        300	500186	coupling	1
        301	B081016423	Screw, 1/2UNC*2GR: Unbrako galvanized internal hex head screw	8
        302	501532	Fixing plate	1
        303	B081010221	Screw, 1/2UNC*1-1/4GR:5 galvanized hexagonal head	2
        304	509097	Safety lock wire, 1.25mm diameter	1
        305	506348	gasket	1
        	500186	Coupling**
        306	503880	Drive components	1
        307	507645	Flywheel friction plate	1
        308	507646	Centamax Hub	1
        309	507647	Screw assembly	1
        310	503026	Transmission and mounting components	1
        311	502659	transmission	1
        312	503187	Front bracket – gearbox	1
        313	B121018221	Screw, 3/4UNC*2-1/4GR:5 galvanized hexagonal head	4
        314	B121028221	Screw, 3/4UNC*3-1/2GR:5 galvanized hexagonal head	4
        315	B161020221	Screw, 1UNC*2-1/2GR:5 galvanized hexagonal head	2
        316	W21222	Washers, 3/4″ springs, galvanized	8
        317	W21622	Washers, 1″ galvanized springs	2
        318	503920	Oil gauge	1
        319	503921	Oil dipstick	1
        320	504138	90° elbow connector 1NPT convex * 1NPT convex	1
        321	505702	Torque converter housing assembly	1
        322	505703	Transmission gearbox assembly	1
        323	505719	32000 Wheel Assembly	1
        324	505760	Turbine shaft stator support assembly	1
        325	505845	Pump drive assembly	1
        326	505849	Reverse and third clutch shaft assembly	1
        327	505851	Reverse and second clutch shaft assembly	1
        328	505855	Low-speed shaft assembly	1
        329	505865	Output shaft assembly	1
        330	506008	Idler shaft and fourth gear clutch assembly	1
        331	506022	Pressure regulating valve and pump assembly	1
        332	506023	Control valve with pneumatic venting stop	1
        333	500382	regulating valve device	1
        334	506087	Pump regulator	1
        335	507965	Input and output flanges	1
        	505702**	Transmission housing assembly**
        336	505283	Pipe plug	1
        337	505284	Torque converter housing and pipe assembly	1
        338	501116	Screw retaining washer	12
        339	505287	Column bolts and nuts	5
        340	505288	screw	7
        341	505289	bolt	5
        342	505290	tubing	1
        343	501097	tubing	5
        344	501100	Transmission housing bushing	2
        345	501099	Torque box housing bushing locking plate	2
        346	505291	Screw retaining washer	6
        347	501082	Pipe clamp screws	4
        348	501095	respirator	1
        349	500910	elbow	1
        350	505294	Breathing device reducing bushing	1
        351	505296	Locking washers	18
        352	505297	screw	4
        353	505295	screw	4
        354	505303	Lubricating oil pipe fixing screws	2
        355	505309	Regulator lubricating oil bypass pipe	1
        356	505310	O-ring of the inhalation tube	1
        357	505311	Inhalation tube gasket	1
        358	505312	Inhalation tube assembly	1
        359	505313	Screws and locking washers	1
        360	505314	pipe clamp	2
        361	505316	Reverse pipe assembly	1
        362	505320	O-ring	2
        363	505331	Lubricating oil pipe assembly	1
        364	505333	Third gear assembly	1
        365	505334	Valve oil supply pipe	1
        366	505335	screw	10
        367	505336	washer	1
        368	501108	Positioning pin	2
        369	501059	Front cover oil seal	1
        370	505337	Torque converter housing front cover	1
        371	505338	washer	1
        372	505340	hose connector	1
        373	505277	Assembly – Hose Return	1
        374	505341	hose connector	1
        	505703**	Transmission gearbox assembly**
        375	504486	Clutch pressure tube O-ring	2
        376	501097	tubing	4
        377	505347	Low-speed clutch pressure pipe	1
        378	505349	Pillar pin	1
        379	505718	Rear cover assembly	1
        380	505357	drain plug	1
        381	504487	Hole plug	1
        382	505369	Pipe plug	2
        383	505378	coarse filter assembly	1
        384	501102	Cover pad	1
        385	504488	Transmission housing and piping assembly	1
        386	505421	Screw plug-box	3
        387	505387	Inhalation tube – clamp	1
        388	505388	Inhalation tube assembly	1
        389	501360	Solenoid valve O-ring	1
        390	505382	Four-position pressure hose	1
        391	505384	Fourth gear clutch lubrication pipe	1
        392	501233	Bearing retaining ring	2
        393	505385	Oil distributor	1
        394	505386	Bearing locking ring	1
        395	505412	Suction tube seat washer screw	2
        396	505413	Inhalation tube seat gasket	1
        397	504489	O-rings in the suction line	1
        398	505415	rivet	5
        399	505416	Oil baffle ring	1
        400	505417	Oil baffle ring	1
        401	501111	Speed sensor adjusting bushing	1
        402	501112	Adjusting bushing shims	2
        403	501109	Speed sensor hole plug	1
        404	504490	O-ring plug	1
        	505718**	Rear cover assembly**
        405	505352	washer	1
        406	504491	Back cover	1
        407	505335	screw	21
        408	505354	Locking washers	23
        409	501104	Pipe plug	1
        410	505355	Column bolts and nuts	2
        411	505356	bolt	2
        	505719	32000 Wheel Assembly**
        412	505435	Turbo hub	1
        413	505436	Reaction device retainer	1
        414	505437	reaction device	1
        415	505438	Reaction device gasket	1
        416	505439	Bearing circlip	1
        417	505440	Impeller hub bearing	1
        418	505441	impeller hub	1
        419	505442	Impeller hub O-ring	1
        420	504492	impeller	1
        421	505444	Impeller hub bolt washers	1
        422	505445	Hub to impeller screw	12
        423	505446	turbine	1
        424	505447	Turbine hub bolt washers	1
        426	504493	Turbo hub bolts	8
        427	505449	impeller to cover O-ring	1
        428	505450	Impeller cover	1
        429	505525	rear bearing flat head screw	24
        430	504467	Adjusting nut, locking bolt, and retaining washer	24
        431	505453	Impeller to cover bearing	1
        432	505454	bearing washers	1
        433	505455	Bearing circlip	1
        434	505456	O-ring from bearing cover to impeller cover	1
        435	505457	Input axis	1
        436	504494	Shaft to impeller cover screws	10
        437	501183	Input shaft bearing	1
        	505760**	Turbine shaft stator support assembly**
        438	501331	screw	6
        439	505425	Stator support screw retaining washer	6
        440	505426	Stator support and bushing assembly	1
        441	505427	turbine shaft	1
        442	505428	Turbine shaft piston rings	1
        443	505429	Turbine shaft bearing	1
        444	505430	Turbine shaft gear circlip	1
        445	505431	Piston rings	1
        446	505432	Oil baffle seal ring	1
        447	505433	Oil baffle ring	1
        448	505434	Oil baffle ring	1
        449	505190	Gear-Impeller Hub 46 Teeth	1
        450	501192	Snap ring – impeller hub	1
        451	505270	26-tooth gear-turbine shaft	1
        	505845**	Pump drive assembly**
        452	505459	Bearing support screws	6
        453	505354	Locking washers	6
        454	505460	Drive gear circlip	3
        455	505472	Pump drive gear bearing	3
        456	505473	Pump drive bearing support	3
        457	505474	Pump drive gear	3
        	505849	Reverse and third clutch shaft assembly**
        458	501194	Piston rings	3
        459	505476	Front bearing retaining ring	2
        460	505478	End cap	1
        461	505479	End cap ball	1
        462	505480	Front bearing	1
        463	505482	The dust seal of the clutch driven gear bearing faces inward.	1
        464	505483	Clutch driven gear bearing retainer	2
        465	501199	Clutch hub retainer oil ring	2
        466	501215	Backplate retaining ring	2
        467	505848	Adapter plate – shaft	1
        468	505485	Clutch outer disc	13
        469	501218	Clutch inner disc	13
        470	508429	Clutch piston assembly	1
        471	501220	Piston outer seal	2
        472	501209	Clutch piston internal seal	2
        473	508426	Clutch piston seal	1
        474	505489	Reverse and third clutch drum and plug assembly	1
        475	505424	Clutch piston assembly	1
        476	501216	end plate	1
        477	501202	Disc spring assembly	1
        478	201201	Spring seat	2
        479	501200	Spring seat retainer	2
        480	505490	Spring seat retainer	1
        481	501240	Piston return spring thrust washer	1
        482	505491	Piston return spring	1
        483	501241	Spring seat	1
        484	505492	Three-stage bearing	1
        485	505493	Three-position bearing retainer	2
        486	505494	Three-stage bearing gasket	1
        487	505496	The dust seal on the third-position bearing faces outwards.	1
        488	505497	Reverse and third axle rear bearing	1
        489	505498	Gear retaining ring	1
        490	505271	Gear – Low Drive 26 Tooths	1
        491	505272	Gear – Third Tooth 52	1
        492	505273	Gear-clutch driven 26 teeth	1
        	505851**	Forward and Second Clutch Shaft Assembly**
        	501194	Piston rings
        	505476	Front bearing retaining ring
        493	507663	ball	1
        494	501235	Front bearing retainer	1
        495	505842	Improved hub side of main bearing housing	1
        496	503220	retaining ring	1
        497	503221	retaining ring circlip	1
        498	505484	end plate	1
        499	505499	Clutch drum and plug assembly	1
        500	505274	Gear – Second 30 teeth	1
        	505855	Low-speed shaft assembly**
        501	501267	idler shaft guide bearing	1
        502	504495	Low speed shaft front bearing outer ring	1
        503	504496	Low speed shaft front bearing inner ring	1
        504	504497	Low-speed gear bearing assembly	1
        505	505510	Low-speed gear – 54 teeth	1
        506	501199	Clutch hub retainer oil ring	1
        507	504498	Washers and bearing gaskets	1
        508	504499	Spring seat retaining ring	1
        509	505430	Turbine shaft gear circlip	1
        510	504500	Spring seat	1
        511	500348	Spring-Waveform	1
        512	500349	Spring seat ring – wave spring	1
        513	501215	Backplate retaining ring	1
        514	505500	end plate	9
        515	505505	Clutch inner disc	9
        516	505485	Clutch outer disc	1
        517	508428	Clutch piston assembly	1
        518	501220	Piston outer seal	1
        519	501209	Clutch piston internal seal	1
        520	508426	Clutch piston seal	1
        521	500350	Low-speed clutch hub retaining ring	1
        522	500351	Low-speed clutch hub and drum assembly	1
        523	500352	Low gear and shaft O-ring	1
        524	500355	Low-speed gear shaft and drum assembly	1
        525	500356	low speed gear shaft	1
        526	500367	Low speed gear shaft plug	1
        527	501287	Front/Rear Bearing Inner Ring	1
        528	501292	Rear bearing outer ring	1
        529	501226	Piston rings	1
        530	500368	Rear bearing cover O-ring	1
        531	500370	Bearing cover gasket-004	AR
        532	500371	Bearing cover gasket-007	AR
        533	500372	Bearing cover gasket-010	AR
        534	500373	Bearing gasket-020	AR
        535	500374	O-ring – pressure tube	1
        536	501104	Pipe plug	1
        537	500375	Rear bearing cover	1
        538	504467	Adjusting nut, locking bolt, and retaining washer	5
        539	505525	rear bearing flathead screw	5
        	505865	Output shaft assembly**
        540	501284	Front and rear bearing cover oil seals	2
        541	505546	Front bearing cover	1
        542	501397	Bearing cover gasket-004	AR
        543	501398	Bearing cover gasket-007	AR
        544	501399	Bearing cover gasket-010	AR
        545	501400	Bearing cover gasket-020	AR
        546	505547	Front bearing cover O-ring
        547	501286	Front bearing outer ring	1
        548	501287	Front/Rear Bearing Inner Ring	2
        549	505548	Output shaft gear shims	1
        550	505549	Output shaft	1
        551	501292	Rear bearing outer ring	1
        552	505550	Rear bearing cover O-ring	1
        553	504484	Rear bearing cover O-ring	1
        554	505552	Rear bearing flat head screw locking washer	4
        555	505553	Front bearing flathead screw	4
        556	505275	Cover – Rear Bearing	1
        557	505276	Gear-output	1
        	506008**	Idler shaft and fourth gear clutch assembly**
        558	508426	Clutch piston seal	1
        559	501209	Clutch piston seal	1
        560	505455	Bearing circlip	1
        561	505515	Clutch drum and hub assembly	1
        562	505528	Idler shaft and plug assembly	1
        563	505529	idler shaft gear key	1
        564	505530	idler shaft gear	1
        565	505531	Idler wheel rear bearing assembly	1
        566	505530	Bearing locating ring	1
        567	505532	idler shaft washer	1
        568	503334	Idler shaft nut	1
        569	503335	idler shaft bearing cover gasket	1
        570	505536	Idler shaft bearing cover	1
        571	505537	Bearing cover screw retaining washer	4
        572	505538	Bearing cover screws	4
        573	501220	Piston outer seal	1
        574	508428	Clutch piston assembly	1
        575	505485	Clutch outer disc	7
        576	501218	Clutch inner disc	6
        577	505500	end plate	1
        578	501215	Backplate retaining ring	1
        579	501199	Clutch hub retainer oil ring	1
        580	501240	Piston return spring thrust washer	1
        581	505491	Piston return spring	1
        582	501241	Spring seat	1
        583	501231	Bearing retaining ring	3
        584	505540	Fourth gear bearing	2
        585	505541	Fourth gear, 23 teeth	1
        586	505542	Fourth gasket	1
        587	505544	Idler shaft front bearing	1
        588	505545	Fourth-gear piston ring	3
        	506022**	Pressure regulating valve and pump assembly**
        589	505555	Air pump drive bushing assembly	1
        590	505556	Pump sleeve retainer	1
        591	505557	Valve to housing gasket	1
        592	505558	Valve body O-ring	1
        593	501139	O-ring	1
        594	505369	Pipe plug	2
        595	505561	Safety valve seat	1
        596	505562	Safety valve gasket	1
        597	505563	Safety valve plunger	1
        598	505564	Safety valve spring	1
        599	501382	O-ring	1
        600	505556	Valve stop O-ring	1
        601	505567	Valve stop rolling pin	2
        602	505569	valve stop	1
        603	505570	O-ring	1
        604	505571	Valve piston	1
        605	505572	Spring valve	1
        606	505573	Spring valve outside	1
        607	505574	Valve to torque converter housing bolts	1
        608	505575	Valve body to pump gasket	1
        609	505576	Pump body retaining ring	1
        610	505577	Thrust plate and bearing (general term)	2
        611	505578	Pump driven shaft assembly	1
        612	505579	Air pump assembly	1
        613	505345	Locking washers	4
        614	505580	Valve to housing post bolts and nuts	4
        615	501302	Thrust plate and bearing assembly	2
        616	501303	wave spring	2
        617	501304	Pump shaft seal	2
        618	505581	Pump to filter adapter screw stop washer	4
        619	505582	Pump to filter adapter screw	4
        620	505583	Pump drive shaft assembly	1
        621	501327	Pump shaft oil seal	1
        622	505584	Pressure regulating valve assembly	1
        623	505585	Valve body rolling pin	3
        624	503165	Valve body O-ring	1
        625	503166	Pump to filter liner	1
        626	503167	Filter adapter tube	1
        627	503168	Bypass filter disc spring	1
        628	503169	Bypass filter disc	1
        629	503170	Bypass filter disc spring seat	1
        630	503171	Filter seat retaining ring	1
        631	503211	O-rings in filter housing	1
        632	503212	Oil filter element	1
        633	503213	Oil filter element spring	1
        634	503225	Filter housing	1
        635	503215	Pipe plug	1
        636	503216	Air pump and oil filter assembly	1
        637	506023**	Control valve with pneumatic venting**	1
        638	501368	Valve oil seal	2
        639	500778	slide valve oil seal ring	2
        640	500726	slide valve oil sealing gasket	2
        641	500728	Forward and reverse slide valves	1
        642	501355	Control valve to regulator gasket	1
        643	501460	Brake spring	3
        644	503219	slide valve spring
        645	501457	Brake ball	4
        646	500757	Neutral switch	1
        647	504485	slide valve	1
        648	502961	Screw plug	1
        649	501024	O-ring plug	1
        650	500378	gasket	1
        651	500758	Control valve housing assembly	1
        652	500759	Brake spring plug	1
        653	501462	Brake spring plug washer	1
        654	500379	O-ring	1
        655	500760	Valve to torque converter housing bolts	9
        666	504467	Adjusting nut, locking bolt, and retaining washer	9
        657	501456	Screw plug	1
        658	500761	Speed selector slide valve	1
        659	503217	gasket	1
        660	501449	Free Throw Valve Assembly	1
        661	501281	O-ring	1
        662	501381	Pneumatic venting oil seal	1
        663	501449**	Neutral release valve assembly**	1
        664	501405	Piston housing stop plug	1
        665	501281	O-ring	1
        666	506415	Import/Export O-rings	3
        667	501379	Pneumatic venting cylinder ring	1
        668	501453	piston	1
        669	501454	Piston housing	1
        670	500382**	Control valve device**
        671	505398	Screw plug	4
        672	501024	O-ring plug	4
        673	500383	Accumulator spring – outer	2
        674	500384	Accumulator spring – inner	2
        675	501350	regulating valve spring	2
        676	500385	Gaskets, regulating valve to housing	1
        677	506087**	Pump regulator**
        678	500386	Pump regulator gasket	1
        679	500387	Pump regulator	1
        680	505354	Locking washers	2
        681	500388	Pump regulator screw	2
        682	504467	Adjusting nut, locking bolt, and retaining washer	2
        683	500389	Pump regulator screw	2
        684	507966	spline adapter	1
        685	507965**	Input and output flanges**
        686	500883	Output flange	2
        687	501474	Nut-Output Flange	2
        688	501475	Washer – Output Flange	2
        689	501045	O-ring	2
        690	501465	Input flange	1
        691	501477	Nut – Input Flange	1
        692	501478	Gasket – Input Flange	1
        693	502179	O-ring	1
        694	503027	Front axle and mounting components
        695	503222**	Shaft assembly**	1
        696	503224	screw shaft	8
        697	N202521	Nuts, 1-1/4′ UNFGR: 10.9 galvanized standard	16
        698	W22032	“Washers, 1-1/4” Hard flat galvanized	16
        699	505225	Differential breather bracket	1
        700	501498	Wheel nuts 3/4 UNF	38
        701	501041	Wheel thread washer 3/4 UNF	38
        702	503222**	Shaft assembly**
        703	506398	Internal gear hub	2
        704	505370	Bearing adjusting nut	2
        705	505371	Shaft forming adjusting nut lock	2
        706	505372	Shaft forming adjusting ring	2
        707	505377	Sun gear thrust washer	2
        708	505374	Sun Gear	2
        709	505358**	Planetary gear carrier assembly**	1
        710	501026	Differential bracket connecting gasket	54
        711	505373	bracket flat head screw	40
        712	502961	Screw plug	3
        713	506399	axle	2
        714	505366	outer hub bearing inner ring	2
        715	505380	Outer ring of outer hub bearing	2
        716	500886	wheel bolts	38
        717	505461	Hub and steel cup assembly	2
        718	500888	Wheel post bolts and nuts	38
        719	505381	Inner hub bearing outer ring	2
        720	505367	Inner ring of inner hub bearing	2
        721	500891	Hub surface seal	2
        722	501038	respirator	2
        723	506420	case	1
        724	500913	Ingot-shaped shaft connecting stud	1
        725	506403	Ingot shaft	32
        726	505279	Sealing – Spindle Shaft to Housing	2
        727	506404**	Brake assembly**	2
        728	500919	Ingot-shaped shaft connecting stud washer	2
        729	505394	Ingot shaft fixing column bolts and nuts	32
        730	500927	Housing discharge hole plug	1
        731	506405**	Differential and bracket assembly**	1
        732	505281	Flathead screws – differential positioning and fixing	2
        733	505280	Bracket fixing – flat head screw	12
        734	505358**	Planetary gear carrier assembly**
        735	505359	Planetary gear carrier	1
        736	500989	Thrust Washer	1
        737	505365	Pressure plate screws	6
        738	505339	pressure plate	3
        739	505364	Thrust Washer	6
        740	505360	Pinion needle roller	168
        741	505362	Planetary gears	4
        742	505285	Planetary gear needle roller washers	3
        743	505361	Planetary gear shaft	3
        744	505363	Planetary gear shaft O-ring	3
        745	506404	Brake assembly**
        746	506413**	Multi-disc assembly**
        747	502958	Brake fluid plug	2
        748	500999	O-ring	3
        749	502964	(For venting) Screw with hole	2
        750	501000	Screw plug 9/16-18 – including part #501001	2
        751	501001	O-ring	2
        752	501002	Brake fluid filler plug	1
        753	501003	Brake fluid adder plug O-ring	1
        754	501004	Screw plug	2
        755	506414	Brake box	1
        756	501003	Import/Export “O-ring”	2
        757	501007	Braking spring	15
        758	501008	Outer cover O-ring seal	1
        759	501009	Piston pressure ring	1
        760	501010	External piston seal assembly	1
        761	502892	Differential and bracket connecting screw washer	12
        762	501012	Brake cover	12
        763	501013	Friction disc and bearing assembly	1
        764	501014	Reverse eclipse	6
        765	502974	Internal piston seal	1
        766	501016	Brake piston	1
        767	501056	Wear indicator needle	1
        768	506417	Indicator pin O-ring	2
        769	501019	Guide and wear needle indicator assembly	1
        770	501020	Warning signs	2
        771	501021	Sign cover	2
        772	501022	Sign cover screws	2
        773	501023	Sealing ring kit	1
        774	506405**	Differential and bracket assembly**
        775	506406	External clutch disc	8
        776	506407	Internal clutch disc	6
        777	505464	Small gear and side gear kit	1
        778	505306	Seat spring	2
        779	506408	Disc spring	4
        780	505301	Small gear thrust washer	4
        781	505299	Needle roller	24
        782	505300	Internal needle roller thrust washers	4
        783	505305	outer center pin thrust washer	8
        784	505307	cross shaft	1
        785	501026	Differential bracket connecting washer	12
        786	505395	Box screw	12
        787	505396	Gear ring flat head screw nut	12
        788	505315	Gear ring flat head screw	12
        789	505325	Small gear internal bearing	1
        790	505568	Differential bracket screws	4
        791	500958	Differential bracket flat head screw locking washer	8
        792	502899	Differential adjusting nut lock	2
        793	504467	Adjusting nut, locking bolt, and retaining washer	4
        794	501047	Adjusting nut and locking screw	2
        795	505319	Differential adjusting nut	2
        796	505318	Differential bearing outer ring	2
        797	505317	Differential bearing inner ring	2
        798	505465	Differential bracket and cover assembly	1
        799	505324	Inner ring of the central pinion bearing	1
        800	505343	outer ring of the central pinion bearing	1
        801	506409	Pinion bearing gasket kit	10MM
        802	505321	Bearing cover thin gasket – medium	10MM
        803	505322	Bearing cover thin gasket – thick	20MM
        804	505467	pinion bearing cover and bearing cup assembly	1
        805	505342	outer ring of external pinion bearing	1
        806	505323	outer pinion bearing inner ring	1
        807	505399	Gear seal seat fixing flat head screw	1
        808	505400	Gear seal seat fixing washer	1
        809	505345	small gear sealing gasket	1
        810	505344	Small gear oil seal	1
        811	504477	Seat – Pinion Seal	1
        812	505402	Oil seal seat locking washer	7
        813	506410	Oil seal base flat head screw	7
        814	505348	V-ring seal	1
        815	505351	Combined flange assembly	1
        816	505327	pinion shaft nut	1
        817	505328	Gaskets – O-rings	1
        818	505329	O-ring	1
        819	506411	Gear ring and pinion kit	1
        820	506412	Differential body and split assembly	1
        821	505470	Differential gearbox assembly	1
        822	503028	Rear axle and mounting components
        823	503222**	Shaft assembly**	1
        824	503226	Screw shaft – rear axle support	8
        825	503227	Rear axle support	1
        826	503228	Pin-rear axle support	2
        827	503230	Cover – Rear Axle Support	4
        828	503231	Buffer – Rear Axle Support	4
        829	N202521	Nuts, 1-1/4′ UNFGR: 10.9 galvanized standard	16
        830	W22032	“Washers, 1-1/4” Hard flat galvanized	16
        831	B081016221	“Screw, 1/2UNC×2″GR:5 galvanized hexagonal head”	12
        832	W20822	Washers, 1/2 springs (galvanized)	20
        833	N081021	Nuts, 1/2 UNCGR:5 galvanized standard	8
        834	505225	Differential breather bracket	1
        835	500762	bushing	6
        836	504386	Shock absorber rear axle support thin washer	A/R
        837	501498	Wheel nuts 3/4 UNF	38
        838	501041	Wheel spacer 3/4 UNF	38
        839	507300	Rear differential brake hose bracket	1
        840	503029	Transmission control components
        841	500411	Steering stick	1
        842	500412	Gear lever	1
        843	500413	Mounting bracket transmission	2
        844	503903	bracket-transmission	1
        845	500416	Crank lever mechanism transmission	2
        846	504090	Bracket control	1
        847	500418	Bushing Transmission	1
        848	500419	Wire rope gearbox	1
        849	B051005423	“Screw, 5/16UNC×5/8″GR:5 galvanized hex socket head cap screw”	4
        850	500420	Ball joint gearbox	8
        851	500421	Shifter	2
        852	506686	Linkage-Direction	1
        853	506687	Connecting rod-transmission	1
        854	B101022221	“Screw, 5/8″UNC×2-3/4″GR:5 galvanized hexagonal head”	2
        855	W21022	Washers, 5/8 springs (galvanized)	2
        856	N081213	“Nuts, 1/2 UNCGR:5 Black Nylon”	2
        857	W20832	Washers, 1/2″ hard-faced galvanized	2
        858	BW04270409	“Grease, 1/8″ BSP, straight”	2
        859	504506	Cable Gearbox	1
        860	503030	Drive chain components
        861	503194**	Drive shaft transmission**	1
        862	503195**	Drive shaft front axle**	1
        863	503196**	Drive shaft steering**	1
        864	503197**	Drive shaft rear axle**	1
        865	503198**	Drive shaft engine to transmission	1
        866	504503	Bracket drive shaft	1
        867	504352	Safety bracket	1
        868	504353	Safety bracket	1
        869	B081008221	“Screw, 1/2″ UNC x 1″ GR:5 galvanized hexagonal head”	2
        870	W20822	“Washer, 1/2” Spring Galvanized	2
        871	500490	1/2 boss	2
        872	P082016321	“Screw, 1/2″ UNF×2G” GR:8 Galvanized Hex Head”	12
        873	N082321	“Nuts, 1/2″ UNF x 2” GR:8 galvanized standard	12
        874	B06201621	“Screw, 3/8″ UNF×2″ GR; 8 galvanized hexagonal head”	4
        875	N062321	“Nuts, 3/8” UNF GR:8 galvanized standard	4
        876	503194**	Drive shaft transmission**
        877	501591	Universal joint	1
        878	506191	Welding fork	1
        879	506174	Tube	1
        880	506175	short axis	1
        881	506176	end fork	1
        882	500708	Nut	1
        883	506178	hard washers	1
        884	506959**	Bearing assembly**	1
        885	506597	case	1
        886	506598	Bearing with locking device	1
        887	503195**	Drive shaft front axle**
        888	501591	Universal joint	1
        889	506176	end fork	1
        890	506175	short axis	1
        891	506183	Tube	1
        892	506184	short shaft protrusion	1
        893	506189	Sliding fork	1
        894	500780	Nut	1
        895	506178	hard washers	1
        896	506959**	Shaft assembly**	1
        897	503169**	Drive shaft steering**
        898	506189	Sliding fork	1
        899	506190	short shaft protrusion	1
        900	501591	Welding fork	1
        901	506192	Tube	1
        902	501591	Universal joint	2
        903	503197	Drive shaft rear axle**
        904	506172	Sliding fork nut	1
        905	506179	Sliding fork male	1
        906	501591	Universal joint	2
        907	503198**	Drive shaft engine to transmission**
        908	506679	Sliding fork	1
        909	506678	short head	1
        910	506677	Welding fork	1
        911	504429	Universal connector 6C	2
        912	503593	Wheel and tire components
        913	507793**	Wheel assembly – inflated **
        914	503582	wheel rim	1
        915	503583	Tire – 17.5×25	1
        916		Section 4: Hydraulic System
        917	503584	Hydraulic pumps and mounting components
        918	503934	Pump Master – Tools	1
        919	503935**	Pump steering and braking**	1
        920	503936	Pump, alternator, and fan	1
        921	507846**	Hose box discharge port**	1
        922	506231	flange	2
        923	506243	1-5/8” JIC rotated 90°	3
        924	506236	1-1/16”UNO×1-1/16”JIC90°	1
        925	506245	1-7/8” UNO x 1-5/8” JIC straight	1
        926	506235	1-5/8” UNO × 1-5/8” JIC90°	1
        927	506239	flange	1
        928	506240	flange	1
        929	506241	flange	1
        930	506242	1”BSPP×1-1/16”JIC straight pipe fitting	1
        931	507412	Suction connector	1
        932	503937	Washer tool pump to transmission	1
        933	503938	Gasket Steering/Brake Pump to Transmission	1
        934	503939	Gasket Alternator/Fan Pump to Transmission	1
        935	503935**	Pump steering and braking**
        936	506830	shaft seal	1
        937	506831	Pin-distribution plate	2
        938	506832	Rotating Inclined Plate	1
        939	506833	Balance pin	1
        940	506834	Servo Piston	1
        941	506835	slider limit ring	1
        942	506836	spherical seat	1
        943	506837	Spring-Barrel	1
        944	506838	Spring-Serving	1
        945	506839	ball	1
        946	506840	Screw plug – Servo assembly	1
        947	506841	Balance shaft cover assembly	2
        948	506842	Spool valve and sleeve assembly	1
        949	506843	Bleeding assembly	1
        950	506844	Seat-Spring	1
        951	506845	spring	1
        952	506846	O-ring	1
        953	506847	O-ring	1
        954	506848	Screw plug	1
        955	506849	Screw plug	1
        956	506850	seat	1
        957	506851	Bucket Liner	1
        958	506852	Snap ring	1
        959	506853	Snap ring	1
        960	506854	Snap ring	2
        961	506855	Piston assembly	5
        962	506856	bucket	1
        963	506857	Shaft-Key-Assembly	1
        964	506858	Distribution plate	1
        965	506859	Casing – Right-hand side	1
        966	506860	Balance shaft housing	1
        967	506861	Cap screw	4
        968	506862	Adjustable differential pressure assembly	1
        969	506863	Screw plug	1
        970	506864	Maximum volume stop “Adjustment 2” assembly	1
        971	506845	Pressure compensation assembly	1
        972	506866	Torque plug assembly	1
        973	506867	Hole plug	1
        974	507864	Hose box discharge port**
        975	507847	Butt bolts	1
        976	507848	seal	1
        977	507849	mating joint	1
        978	507850	hose	1
        979	507851	hose tail	1
        980	507852	plastic lid	2
        981	506227	Steering pipeline assembly
        982	503940	The track steering valve does not have a pressure relief body.	1
        983	500124	“5.7-liter accumulator, steering”	1
        984	505122	Steering wheel	1
        985	500144	Turn the handle, turn the steering wheel	1
        986	505593	Cover – Turn	1
        987	504097	Mounting accumulator	2
        988	505100	Bracket – Steering Valve	1
        989	B061008221	“Screw, 3/8” BNC×1GR:5 galvanized hexagonal head	4
        990	W20622	“Washer, 3/8” Spring Galvanized	4
        991	B101022221	“Screw, 5/8” UNC×2-3/4GR:5 galvanized hexagonal head	2
        992	W21022	“Washer, 5/8” Spring Galvanized	2
        993	N081221	“Nut 1/2” UNC GR:5 galvanized standard	2
        994	W20812	“Washer 1/2” flat galvanized	2
        995	502852	Shoulder screw, 3/8″ diameter x 1-1/2″ length	1
        996	507660	Top plate accumulator bracket	1
        997	503940	The track steering valve does not have a pressure relief body.
        998	506666	Sealing kit	1
        999	506667	Screw cap	7
        1000	506668	Broken cap	1
        1001	506669	Internal gear oil pump	1
        1002	506670	Wear-resistant plate	1
        1003	506672	Determination	1
        1004	506673	Needle thrust bearing	1
        1005	506674	Bearing race	2
        1006	506675	Front bezel	1
        1007	506671	drive lever	1
        1008	500124**	5.7-liter accumulator, steering**
        1009	501802	The accumulator itself, 5.69 liters	1
        1010	501803	“Hydraulic cover, accumulator”	1
        1011	501805	“Gas cap, accumulator”	1
        1012	501806	“Piston, accumulator”	1
        1013	501818**	“Sealing kit, accumulator”**	1
        1014	501808	“Protective valve, accumulator”	1
        1015	501809	“Screw protection valve, accumulator”	1
        1016	501810	“Warning sign, accumulator”	1
        1017	501816	“Gas valve assembly, accumulator”	1
        1018	501818**	“Sealing kit, accumulator”**
        1019	501807	Teflon piston ring accumulator	2
        1020	501812	“VO-shaped coil, energy accumulator”	1
        1021	501813	“Protective gasket for sealing ring, accumulator”	2
        1022	501814	“End-sealed body, accumulator”	2
        1023	501815	“Protective gasket for sealing ring, accumulator”	2
        1024	501817	“O-ring valve, accumulator”	1
        1025	503034	Steering cylinder and mounting components
        1026	503070**	Steering cylinder**	1
        1027	502297	Pin-Steering	2
        1028	502298	Bushing-Steering	4
        1029	B081036221	“Screw, 1/2″ UNC×4-1/2″ GR:5 galvanized hexagonal head”	2
        1030	N081225	“Nut, 1/2” UNCGR:5 galvanized lock	2
        1031	503070**	Steering cylinder**
        1032	504664**	Steering cylinder assembly**	1
        1033	502801	spherical bearings	2
        1034	503210	Spring retaining ring for steering cylinder	2
        1035	504664**	Steering cylinder assembly**
        1036	503204	Linkage rod – steering cylinder	1
        1037	B121024412	3/4UNC×3BLK socket head cap screw	6
        1038	W21232	Washers, 3/4 hard flat galvanized	6
        1039	503208	Sealing kit – Steering cylinder	1
        1040	503205	Head sealing tube – steering cylinder	1
        1041	503206	Bucket – Steering Cylinder	1
        1042	503207	Piston-Steering Cylinder	1
        1043	R10601090	Rolling pin, metric M6×90mm, galvanized	1
        1044	504298	Safety valve cylinder	2
        1045	504299	Connector grease nipple	3
        1046	DUD62-12	“Connector, plug 3/4” UNO protrusion	2
        1047	DUD62-09	“Connector, Plug 9/16UNO”	3
        1048	503035	Lifting cylinder and mounting components
        1049	503071**	Lift cylinder assembly**	2
        1050	503130	Pin top – lifting cylinder	2
        1051	504918	Flow control	1
        1052	503131	Pin-bottom lifting cylinder	2
        1053	500149	Bushing-70	12
        1054	500498	cover plate	8
        1055	B061006221	“Screw, 3/8” UNC×3/4 GR:5 galvanized hexagonal head	32
        1056	W20622	Washers, 3/8 galvanized springs	32
        1057	BW04272203	Grease nipple, 1/4, BSP, straight	8
        1058	503071**	Lift cylinder assembly**
        1059	504678**	Lift cylinder assembly**	1
        1060	500150	Flange-mounted bushing, 70mm inner diameter × 80mm outer diameter	4
        1061	503127	Bucket-lifting cylinder	1
        1062	503128	Connecting rod-lift cylinder	1
        1063	503126	Lift cylinder head sealing tube	1
        1064	500051**	Sealing kit**	1
        1065	502330	Load inspection – lifting cylinder	1
        1066	502331	Pipe lifting cylinder	1
        1067	B121020423	“Screw, 3/4” UNC×2-1/2 GR: Undrako galvanized hex socket head cap screws	8
        1068	W21232	Washers, 3/4 hard flat galvanized	8
        1069	503077	cam screw connection	2
        1070	DUD279-14	Connector, metric plug M14×1.5	1
        1071	DUD62-09	Connector, 9/16 UNO screw plug	1
        1072	DUD62-12	Connector, 3/4 UNO screw plug convex	1
        1073	BW04483102	Shaft shoulder bolt M12×1.75 0.32T maximum torque	1
        1074	B051032221	Screw, 5/16UNC×4GR:5 galvanized hexagonal head	2
        1075	W20522	Washers, 5/16 galvanized springs	2
        1076	R10601090	Rolling pin, metric M6×90mm, galvanized	1
        1077	500051**	Sealing kit**	1
        1078	501605	bezel	1
        1079	501606	Sealing tube sealing O-ring	1
        1080	501607	bearing ring	2
        1081	501608	Piston seal	1
        1082	501609	Piston rod scraper	1
        1083	501610	Main seal	1
        1084	501611	O-ring	1
        1085	501612	bearing ring	2
        1086	501613	Piston seal O-ring	1
        1087	503036	cylinder tilting and mounting components	1
        1088	503072**	cylinder assembly	1
        1089	503138	Pin top – swing cylinder	1
        1090	503139	Pin bottom – swing cylinder	1
        1091	503140	Bushing-Swing Cylinder-Connection	4
        1092	503141	cover plate	4
        1093	B061006221	Screw, 3/8UNC×3/4GR:5 galvanized hexagonal head	24
        1094	W20622	Screw, 3/8 spring, galvanized	24
        1095	BW04272203	Grease nipple, 1/4, BSP, straight	4
        1096	503072**	cylinder assembly
        1097	504782	Arranged cylinders	1
        1098	503137	Bushing-Swing Cylinder-Z-Connection	4
        1099	504782	Arranged cylinders
        1100	504783	Bucket-swinging tank	1
        1101	503133	Connecting rod-swing cylinder	1
        1102	504784	Piston-Oscillator	1
        1103	504785	Head sealing tube	1
        1104	504786	Sealing kit – swing cylinder	1
        1105	501616	Load check	1
        1106	R10601090	Rolling pin, metric M6×90mm, galvanized	1
        1107	B121032423	3/4″ UNC x 3, GR:12.9 galvanized internal hex head screws	8
        1108	W21232	Washers, 3/4 hard flat galvanized	8
        1109	DUD62-12	Connector, 3/4 UNO screw plug convex	2
        1110	DUD62-09	Connector, 9/16 UNO screw plug	2
        1111	BW04272203	Grease nipple, 1/4, BSP, straight	2
        1112	BW04483102	Shaft shoulder bolt M12×1.75 0.32T maximum torque	1
        1113	503037	Hydraulic cylinder oil supply pipe assembly
        1114	DUD52-1712	Connector pipe fitting 1-1/16UNO convex × 3/4JIC convex	2
        1115	504234	90° elbow connector 3/4JIC convex × 3/4JIC convex	4
        1116	DUD53-1712	90° elbow connector 1-1/16 UNO convex × 3/4 JIC convex	4
        1117	DUDA82-121212	Connector T-shaped 3/4JIC convex × 3/4JIC concave × 3/4JIC convex	2
        1118	DUDA13-1712	Connector pipe reduction 1-1/16JIC concave × 3/4JIC convex	2
        1119	DUD53-1212	90° elbow joint 3/4 UNO convex × 3/4 JIC convex	2
        1120	504235	90° elbow connector 1-1/16JIC convex × 1-5/16UNO convex	1
        1121	504236	Connector T-shaped 1-5/8JIC convex × 1-5/8JIC concave × 1-5/8JIC convex	1
        1122	DUD52-2117	Connector pipe fitting 1-5/16UNO convex × 1-1/16JIC convex	2
        1123	DUD50-1717	90° elbow connector 1-1/16JIC convex × 1-1/16JIC concave rotation	2
        1124	504345	Hose hydraulic 1/2×1230×3/4JIC	1
        1125	504347	Hose hydraulic 1/2×1380×3/5JIC	3
        1126	504348	Hose hydraulic 1/2×1550×3/6JIC	1
        1127	504346	Hose hydraulic 1/2×1120×3/7JIC	1
        	504931	Bucket pipeline assembly
        1128	503941**	Bucket Valve 4 Select**	1
        1129	500128**	Control valve**	1
        1130	501542**	4-way joystick control**	1
        1131	DUD52-0909	Connector, pipe fitting 9/16 UNO convex × 9/16 JIC convex	3
        1132	DUD50-0909	Connector adapter tube joint 90 degrees 9/16JIC convex × 9/16JIC convex	2
        1133	DUD53-0907	90° elbow joint, 9/16 UNO convex head × 7/16 JIC convex head	9
        1134	DUD52-0907	Connector pipe fitting 9/16UNO convex × 7/16JIC convex
        1135	DUD62-09	Connector, screw plug 9/16UNO	1
        1136	DUDA82-090909	Connector T-shaped 9/16JIC convex × 9/16JIC concave × 9/16JIC convex	2
        1137	DUD53-0909	90° elbow connector 9/16 UNO convex × 9/16 JIC convex	1
        1138	DUD50-0707	90° elbow 7/16 UNO convex × 7/16 JIC concave connector	1
        1139	DUDE53-0909	90° elbow extension 9/16 UNO convex × 9/16 JIC convex	1
        1140	DUDA13-0907	Connector 90 reduced diameter 9/16JIC concave × 7/16JIC convex	1
        1141	504332	Hose hydraulic 1/4×1650×7/16JIC	4
        1142	504337	Hose hydraulic 1/4×2800×7/16JIC	4
        1143	504338	Hose hydraulic 1/4×655×7/16JIC	1
        1144	504341	Hose hydraulic 1/4×1000×7/16JIC	1
        1145	504339	Hose hydraulic 1/4×1450×7/16JIC	1
        1146	504340	Hose hydraulic 1/4×1400×7/16JIC	1
        1147	504918	Flow control	1
        1148	503941**	Bucket valve 4 selection**	1
        1149	506272	Sealing kit	1
        1150	500128**	Control valve**
        1151	502235	“Single control, control valve”	2
        1152	503535	Sealing kit	1
        1153	501542**	4. Joystick control**
        1154	507371	Knotted rope	1
        1155	507372	“Sealed, surface”	1
        1156	507373	dust cover	1
        1157	507374	handle	1
        1158	507375	clip	1
        1159	503039	Transmission pipeline assembly
        1160	502447	Transmission oil cooler	1
        1161	506225	Transmission Cooler Base 1	1
        1162	506226	Transmission Cooler Base 2	1
        1163	504254	Connector diameter reduction 1-5/8 JIC concave × 1-1/16 JIC convex	2
        1164	D2900-12-250-17	“Hose, Hydraulic 3/4” × 2500 × 1-1/16 JIC	2
        1165	DUD52-1717	Connector, pipe fitting 1-1/16 UNO convex × 1-1/16 JIC convex	2
        1166	503040	Brake line assembly
        1167	500139**	Brake valve**	1
        1168	500132**	“Accumulator 1.9 liters, braking”**	1
        1169	500321**	Main hydraulic manifold block**	1
        1170	500121**	Pressure filter turn**	1
        1171	504255	Connector pipe fitting 1-5/8UNO convex × 1-1/16JIC convex	1
        1172	504213	Connector diameter reduction 3/4 JIC concave × 9/16 JIC convex	1
        1173	504169	Connector diameter reduction 9/16 JIC concave × 7/16 JIC convex	1
        1174	DUD53-1412	“Connector, 90° elbow 7/8” UNO convex × 3/4 JIC convex	2
        1175	DUD50-0707	“Connector, 90° elbow 9/16” UNO convex × 7/16 JIC convex	1
        1176	DUD52-0907	Connector pipe fitting 9/16UNO convex × 7/16JIC convex	3
        1177	DUD50-1212	Connector adapter tube joint 90 degrees 3/4 JIC convex × 3/4 JIC convex	5
        1178	504223	Connector pipe fitting 7/8UNO convex × 3/4JIC convex 1	1
        1179	504187	Connector T-shaped 7/16JIC convex × 7/16JIC concave × 7/16JIC convex	1
        1180	DUD52-2117	Connector pipe fitting 1-5/16UNO convex × 1-1/16JIC convex	1
        1181	DUD50-1717	Connector, pipe fitting 1-1/16 UNO convex × 1-1/16 JIC convex	2
        	504257	90° elbow connector 1BSPP convex × 1-1/16JIC convex	2
        	504562	Hose hydraulic 1/4×1200×7/16JIC	1
        	504252	90° elbow joint 1-5/8JIC convex × 1-5/8JIC convex rotating	1
        	DUD52-1717	Connector, pipe fitting 1-1/16 UNO convex × 1-1/16 JIC convex	1
        1182	DUDA13-1712	Connector pipe diameter reduction 1-1/16 JIC concave × 3/4 JIC convex	1
        	503793	Manifold Braking	2
        1183	504184	Connector pipe fitting 7/16″ JIC convex × 1/4″ BSPP concave swivel	1
        1184	504230	90° elbow connector 9/16 convex × 9/16 JIC concave	2
        1185	DUD53-1209	90° elbow connector 3/4″ UNO convex × 9/16″ JIC convex	1
        1186	504342	Hose hydraulic 3/8×700×9/16JIC	2
        1187	504609	Hose hydraulic 1-1/4×445×1-5/8JIC	1
        1188	504200	Multi-head T-shaped connector 9/16JIC convex × 9/16JIC convex × 9/16JIC convex	1
        1189	504600	Hose hydraulic 3/4×3250×1-4/16JIC	1
        1190	504323	3/4×2100×1-1/16JIC	1
        1191	504559	Hose hydraulic 1/4×1100×7/16JIC	1
        1192	D2900-08-50-12	Hose, hydraulic 1/2″×500×3/4″ JIC	2
        1193	DUD53-0907	90° elbow joint, 9/16 UNO convex head × 7/16 JIC convex head	1
        1194	504253	Connector pipe fitting 1-16UNO convex × 1-5/8JIC convex	1
        1195	D2900-08-160-12	Hose, hydraulic 1/2″×1600×3/4″ JIC	1
        1196	D2900-08-250-12	Hose, hydraulic 1/2″×2500×3/4″ JIC	1
        1197	DUD62-12	Connector, 3/4 UNO screw plug convex	1
        1198	504344	Hose hydraulic 3/8×1100×9/16JIC	1
        1199	504199	45° elbow joint, 9/16JIC concave swivel joint, 9/16JIC convex swivel joint.	3
        1200	DUD52-1209	Connector pipe fitting 3/4 UNO convex × 9/16 JIC convex	3
        1201	DUD52-0809	Connector pipe fitting 1/2 UNO convex × 9/16 JIC convex	4
        1202	DUD20-090909	Connector T-shaped 9/16JIC convex × 9/16JIC convex (T-shaped) × 9/16JIC convex	1
        1203	DUDA20-090909	Connector T-shaped 9/16JIC convex × 9/16JIC concave × 9/16JIC convex	1
        1204	504560	Hose, hydraulic 3/8″×2950×9/16″JIC	1
        1205	504330	Hose, hydraulic 3/8″×2100×9/16″ JIC	1
        1206	D2900-08-250-12	Hose, hydraulic 1/2″×2400×3/4″ JIC	1
        1207	504343	Hose, hydraulic 3/8″×2000×9/16″ JIC	2
        1208	504297	Connector 4 screw flange × 1-5/8 JIC convex	1
        1209	504097	Mounting accumulator	2
        1210	N081221	Nut, 1/2″ UNC GR:5 galvanized standard	4
        1211	W20812	Washer, 1/2″ flat galvanized	2
        1212	505836	Filter holder	1
        1213	507660	Top plate accumulator bracket	1
        1214	500139	Brake valve**
        1215	501678	Kit – Complete Rebuild – Brake Valve	1
        1216	501679	Kit – Seal – Brake Valve	1
        1217	501680	Valve – Ball Assembly – Brake Valve	1
        1218	501681	Slipper assembly – brake valve	1
        1219	501682	Piston assembly – brake valve	1
        1220	507370	Thin gasket kit	1
        1221	507402	Brake valve spring	1
        1222	500123	1.9-liter accumulator, brake**
        1223	501810	Accumulator body, 1.9 liters	1
        1224	501803	Hydraulic cover, accumulator	1
        1225	501806	Piston, accumulator	1
        1226	501805	Gas cap, accumulator	1
        1227	501807	Teflon piston ring accumulator	2
        1228	501808	Protective valve accumulator	1
        1229	501809	Screw protection valve, accumulator	1
        1230	501810	Warning signs, accumulators	1
        1231	501812	VO-type ring, accumulator	1
        1232	501813	Protective gasket for sealing ring, accumulator	2
        1233	501814	End-sealing of this problem, accumulator	2
        1234	501815	Protective gasket for sealing ring, accumulator	2
        1235	501816	Gas valve assembly, accumulator	1
        1236	501817	O-ring valve, accumulator	1
        1237	501818	Sealed kit accumulator**	1
        1238	501818	Sealed kit accumulator**
        1239	501807	Teflon piston ring accumulator	1
        1240	501812	VO-type ring, accumulator	2
        1241	501813	Protective gasket for sealing ring, accumulator	2
        1242	501814	End-sealing of this problem, accumulator	2
        1243	501815	Protective gasket for sealing ring, accumulator	1
        1244	501816	Gas valve assembly, accumulator	1
        1245	501817	O-ring valve, accumulator
        1246	500321	Main hydraulic manifold block**
        1247	502299	Safety Valve – Cylinder (Sealing Kit 507809)	1
        1248	502100	Guided inspection (normal opening) (Sealing kit 507854)	1
        1249	502101	One-way valve (sealing kit 507809)	2
        1250	502102	Accumulator (Sealing Kit 507810)	2
        1251	502103	Parking brake valve (sealing kit 507810)	1
        1252	502104	Directional control valve (3/2) (Sealing kit 507855)	1
        1253	502105	Pressure reducing valve (sealing kit 507811)	1
        1254	502106	Control valve (sealing kit 507811)	1
        1255	502107	One-way valve (sealing kit 507813)	2
        1256	506815	Pressure relief valve	1
        1257	508182	Aptamers (CETOP5)	1
        1258	508183	O-ring (12.42×1.78)	4
        1259	508184	Screw assembly	1
        1260	508185	Screw assembly	1
        1261	500121**	Pressure filter turn**
        1262	501785	“Head, pressure filter”	1
        1263	501786	“Bowl, pressure filter”	1
        1264	501787	Bypass pipe, pressure filter	1
        1265	501788	Bypass piston, pressure filter	1
        1266	501789	“3.5 bar spring, pressure filter”	1
        1267	501790	Hexagonal nuts, pressure filters	1
        1268	501791	“O-rings, BS124, pressure filters”	1
        1269	501792	“O-rings, BS235, pressure filters”	1
        1270	501793	Anti-crush ring, pressure filter	1
        1271	501794	“Drive screw, pressure filter”	1
        1272	501795	“Model nameplate, pressure filter”	1
        1273	501796	Nameplate, pressure filter	1
        1274	502166	“O-rings, filters”	1
        1275	501798	“O-ring BS017, pressure filter”	1
        1276	501799	“Differential pressure ‘pop-up’ indicator with brake reset cylinder, model 3.5 bar, pressure filter”	1
        1277	501800	“5-micron filter element, pressure filter”	1
        1278	506230	Hydraulic oil tank assembly
        1279	500122**	Reflux filter**	1
        1280	500135	Hydraulic oil level gauge	1
        1281	503808	Add port	1
        1282	501533	Valve pressure	1
        1283	DUD59-12	“Connector, plug 3/4” BSPT steel	2
        1284	507057	Return oil filter extension	1
        1285	506765	Spyscope cover	1
        1286	500122**	Return oil filter**
        1287	502149	Housing, reflux filter	1
        1288	502150	Cover – Bypass, Return Oil Filter	1
        1289	502151	Cover screws, return oil filter	9
        1290	502152	Bypass piston, return oil filter	1
        1291	502153	Bypass spring, 1.7 bar return oil filter	1
        1292	502154	Spring seat, return oil filter	1
        1293	502155	Model nameplate, return oil filter	1
        1294	502156	Drive screw, return oil filter	2
        1295	502157	Screw plug, 1/2 BSPF return oil filter	1
        1296	502158	Screw plug seal, return oil filter	1
        1297	502159	O-rings, return oil filter	1
        1298	502160	O-rings, return oil filter	1
        1299	502161	O-rings, return oil filter	1
        1300	502162	Bowl assembly return oil filter	1
        1301	502163	O-ring return oil filter	1
        1302	502164	Gasket return oil filter	1
        1303	502165	O-ring return oil filter	1
        1304	502166	O-ring filter	1
        1305	502167	Gasket return oil filter	1
        1306	502168	Socket return oil filter	1
        1307	502169	Socket pressure screw plug return oil filter	1
        1308	502162	Filter assembly, 10-micron return oil filter	1
        1309	508854	Filter bypass indicator	1
        1310	503042	Accessory Piping Assembly
        1311	501588**	Manifold pressure relief**	1
        1312	507798	one-way valve	4
        1313	507799	Sealing kit	4
        1314	503043	Quick-connect components and tool line assemblies
        1315	506490	Quick Connector Bracket	1
        1316	506520	Power output hose bracket front	1
        1317	500773	Quick connector 3/4 BSPP convex	4
        1318	500772	Quick connector 3/5 BSPP recess	4
        1319	506246	S-series rotary joints	7
        1320	504577	Hose hydraulic 1/2 × 900 × 3/4 JIC	1
        1321	504578	Hose hydraulic 1/2 × 950 × 3/4 JIC	1
        1322	504574	Hose hydraulic 3/4 × 820 × 1/16 JIC	1
        1323	504575	Hose hydraulic 3/4 × 860 × 1/16 JIC	1
        1324	504572	Hose hydraulic 1/2 × 660 × 3/4 JIC	1
        1325	504573	Hose hydraulic 1/2 × 680 × 3/4 JIC	1
        1326	504579	Hose hydraulic 3/8 × 850 × 9/16 JIC	1
        1327	500774	Quick connector 1/2 BSPP recess	1
        1328	500775	Quick connector 1/3 BSPP protrusion	4
        	DUD256-1212	Fittings, pipe fittings 3/4 BSPP convex × 3/4 JIC convex	1
        1330	DUD256-0809	Fittings, pipe fittings 2/1 BSPP convex × 9/16 JIC convex	1
        1331	504581	Hose hydraulic 1/4 × 435 × 7/16 JIC	2
        1332	504580	Hose hydraulic 3/8×435×9/16 JIC	2
        1333	504403	Nameplate power output	1
        1334	504402	Nameplate brakes	1
        1335	DUD256-0609	Fittings, pipe fittings 3/8 BSPP convex × 9/16 JIC convex	1
        1336	507821	Quick connector 3/8 BSPP recess	1
        1337	507822	Quick connector 3/8 BSPP convex	1
        1338	506992	Power output components	1
        1339	500772	Quick connector 3/4 BSPP recess	1
        1340	500773	Quick connector 3/4 BSPP convex	1
        1341	500775	Quick connector 1/2 BSPP convex	1
        1342	507821	Quick connector 3/8 BSPP recess	1
        1343	506984	Nameplate Brakes – Chinese	1
        1344	506985	Nameplate Power Output – Chinese	2
        1345		Section 5: Electricity, Instrumentation and Control
        1346	506949	Electrical Components – China
        1347	506958**	SEMS Engine System – China**	1
        1348	500608	Explosion-proof cable sealing tube with extended support nut M20	14
        1349	507700	Fireproof and anti-static flexible hose, 16mm	30MM
        1350	501893	4-core cable specification 1	30MM
        1351	506953	Explosion-proof junction box	1
        1352	507033**	“The installed time meter assembly is explosion-proof and has 13mm glass.”	1
        1353	507030	Headlight assembly, explosion-proof 13mm glass
        	502212	Light bulb	4
        1354	506957	M25 Explosion-proof Screw Plug	3
        1355	505110**	Safety spark power supply general term**	1
        	D507210	regulator	1
        1356	507002	M25×M20 Explosion-proof Reduced Diameter	1
        1357	505595	Lamp base stand	2
        1358	505596	Lamp base column	2
        1359	503667	bracket lights	4
        1360	506447	Temperature control box base bracket	1
        1361	507698	Stainless steel hose clamps, 16 to 27 mm	14
        1362	507839**	Assembly Spark Seal Barrier**	1
        1363	502213	Screw plug, explosion-proof M20	2
        1364	507699	5mm fiberglass tube	1MM
        1365	B121024221	Screw, 3/4UNC×3 GR:5 galvanized hexagonal head	4
        1366	N121223	Nuts, 3/4 UNC GR:5, galvanized nylon	4
        1367	W21232	Washers, 3/4 hard flat galvanized	4
        1368	B061008221	Screw, 3/8UNC×1 GR:5 galvanized hexagonal head	8
        1369	W20622	Washers, 3/8 galvanized springs	8
        1370	506958**	SEMS Engine System – China**
        1371	506123	Cable – 2 cores x 3m	6
        1372	507390**	Sems Type II Control Box**	1
        1373	505736	SEMS safety spark battery	1
        1374	505757	2-core x 2m cable general term	3
        1375	505758	2-core × 1m cable general term	1
        1376	507220	Sems 02 – China	1
        1377	506137	Temperature sensor 250mm
        1378	506136	Temperature sensor 100mm	2
        1379	506129	Temperature sensor 105°C	2
        1380	506130	Temperature control box 140°C	2
        1381	506158	Temperature control box 147°C	1
        1382	506128	506129	2
        1383	505111	10 PSI pressure sensor	1
        1384	505752	Sems running battery valve assembly	1
        1385	508051	Cable – 2 cores, 4 pins, 2m	1
        1386	505741	Sems coolant loss sensor	1
        1387	506131	Coolant flow switch	1
        1388	508406	Cable – 5 cores, 1.5m	1
        1389	507188	Gas-sensitive element plug	1
        1390	508402**	Sems Test Suite**	1
        1391	507033**	The installed time meter assembly is explosion-proof and has 13mm glass.
        1392	507046	Timer, explosion-proof, 13mm glass	1
        1393	503667	bracket lights	1
        1394	B105020221	Screw, M10×20GR:5 galvanized hexagonal head	4
        1395	W11032	Washers, M10 hard flat galvanized	4
        1396	B061008221	Screw, 3/8 UNC×1 GR:5 galvanized hexagonal head	2
        1397	W20632	Washers, 3/8 hard flat galvanized	2
        1398	506550	Alternator and hydraulic drive
        1399	503839**	Alternator**	1
        1400	507032	Alternator drives motor	1
        1401	503840	casing	1
        1402	507003	Coupling alternator and hydraulic drive	1
        1403	507095	Mounting bracket for alternator and hydraulic drive	1
        1404	506551	Protective cover, – motor generator drive	1
        1405	B051008221	Screw 5/16 UNC×1GR:5 galvanized hexagonal head
        1406	W20522	Washers, 5/16 galvanized springs	4
        1407	B061008221	Screw, 3/8UNC×1 GR:5 galvanized hexagonal head	8
        1408	W20622	Washers, 3/8 galvanized springs	8
        1409	503839**	Alternator**
        1410	504882	coupling	1
        1411	503702	bushing	1
        	503706	diode board	1
        1412	503703	relay	1
        1413	503704	capacitor	1
        1414	503705	Fuse box assembly	1
        1415	503708	The voltage regulator was adjusted to 13V.	1
        1416	503709	Bearing drive end	1
        1417	503710	bearing sliding end	1
        1418	506931	Smes dashboard Chinese component
        1419	505772	Transmission oil temperature gauge	1
        1420	505771	Engine coolant temperature gauge	1
        1421	500434	Valve quick-connect system unlocking	2
        1422	505774	Exhaust gas coolant temperature gauge	1
        1423	505768	Brake accumulator pressure gauge	1
        1424	506928	Control panel hydraulic oil	1
        1425	507820	Instrument adapter	1
        1426	505767	Exhaust gas pressure gauge	1
        1427	500435	Valve horn	1
        1428	505770	Steering accumulator pressure gauge	1
        1429	505765	Engine oil pressure gauge	1
        1430	505766	air pressure gauge	1
        1431	505769	Brake pressure gauge	1
        1432	505773	Exhaust gas pressure gauge	1
        1433	506901	Dashboard	1
        1434	506925	Instrument panel control panel gearbox	1
        1435	506926	Dashboard Accessories	1
        1436	506926	Dashboard Accessories	1
        1437	506927	Dashboard Control	1
        1438	506929	Nameplate Bucket Control	1
        1439	503899	Support frame, bucket control	1
        1440	504100	Bracket Dashboard Control	1
        1441	504101	Cover Instrument Panel Control	1
        1442	504567	Hose Twist Back Pressure	1
        1443	B065030445	M6×30GR: 12.9 stainless steel semi-circular head bolt	1
        1444	504651	Screw 10-24UNC1-1/2 Length	1
        1445	504092	Instrument panel transmission	1
        1446	504425	Cap-Hose	1
        1447	504414	Foot control components
        1448	500745	Seat support	1
        1449	500748	lever brake	1
        1450	504415	support foot control	1
        1451	500750	Protective hose foot control	1
        1452	506473	Throttle control	1
        1453	500752	foot mat	1
        1454	501497	brake pedal	1
        1455	501554	Accelerator pedal	1
        1456	B081048241	Screw, 1/2 UNC×6 GR:5 hex head	2
        1457	N081243	Nut, 1/4″ UNC GR:5 Stainless Steel Nylon	2
        1458	BW04270409	Lubricating nozzle, 1/8, BSP, straight	2
        1459	B041006221	Screw, 1/2UNC×1-1/4, GR:5 galvanized hexagonal head	8
        1460	N041223	Nut, 1/2″ UNC GR:5 galvanized standard	8
        1461	B081010221	Washers, 1/2″ galvanized springs	4
        1462	N081221	Screw, 5/8 UNC×2, GR:5 galvanized hexagonal head	4
        1463	W20822	Washers, 1/2 springs (galvanized)	4
        1464	B101016221	Screw, 5/8 UNC×2, GR:5 galvanized hexagonal head	2
        1465	W21022	Washers, 5/16 galvanized springs	4
        1466	N101321	Nuts, 5/8 UNC GR:8 galvanized standard	8
        1467		Section 6: Framework and Related Components
        1468	503048	Front vehicle driver components
        1469	503109	Forward vehicle chassis	1
        1470	506459	hose support	1
        1471	504394	Steering lock	1
        1472	504432	clamp	1
        1473	503049	Rear frame assembly
        1474	503737**	Rear vehicle chassis**	1
        1475	B121020321	Screw, 3/4UNC×2-1/2 GR:8 galvanized hexagonal head	7
        1476	N121321	Nuts, 3/4 UNC GR:8, galvanized standard	9
        1477	W21212	Washers, 3/4 flat galvanized	20
        1478	503738	Chariot shaft	1
        1479	504557	fence	1
        1480	504367	build	1
        1481	503672	Oil tank guard plate	1
        1482	B121010221	Screw, 3/4 UNC × 1-1/4 GR:8 galvanized	1
        1483	B121028221	Screw, 3/4UNC×3-1/2 GR:5 galvanized hexagonal head	2
        1484	B161022221	Screw, 1 UNC × 2-3/4 GR:5 galvanized hexagonal head	2
        1485	W21612	Washer, 1 flat galvanized	2
        1486	506491	Pipe support	1
        1487	B081006221	Screw, 1/2UNC×3/4, GR:5 galvanized hexagonal head	2
        1488	W20812	Washers, 1/2 flat galvanized	2
        1489	507203	Air rudder	1
        1490	507216	Emission port cover	1
        1491	503737**	Rear frame base**
        1492	503853**	Trailer connection – diameter 47**
        1493	506773	Trailer connecting pin	1
        1494	506774	Trailer hook	1
        1495	503050	Lifting arm assembly
        1496	503078	Lifting boom base	2
        1497	503143	Z-type connecting base frame	1
        1498	503144	Connecting lifting arm	1
        1499	503145	Pin Top – Lifting Arm	2
        1500	503146	Pin-Z connection	1
        1501	503147	Pin bottom – lifting arm	2
        1502	503148	Bushing-Lifting Arm-Z-Connection
        1503	503149	Bushing-lifting arm	8
        1504	503150	Cover plate – Z-type connection	2
        1505	503141	cover plate	10
        1506	503142	cover plate	2
        1507	503138	Pin top – swing cylinder	2
        1508	503137	Bushing-Swing Cylinder-Z-Connection	4
        1509	503140	Bushing-Swing Cylinder-Connection	4
        1510	B061006221	Screw, 3/8 UNC x 3/4 GR:5 galvanized hexagonal head	80
        1511	W20622	Washers, 3/8 galvanized springs	80
        1512	BW04272203	Lubricating nozzle, 1/4, BSP, straight	14
        1513	503817	Lock pin	2
        1514	503818	support	2
        1515	507449	Protective shield	2
        1516	503051	Quick Connect Assembly
        1517	503079	Quick Connect Board	1
        1518	503151**	Quick-connect cylinder assembly**	1
        1519	503153	Locking tongue quick coupler	1
        1520	500072	Sales Express	2
        1521	B081024221	Screw, 1/2 UNC×3 GR:5 galvanized hexagonal head	2
        1522	N081223	Nut, 1/2″ UNC GR:5 galvanized heat exchanger nylon	2
        1523	503151**	Quick-connect cylinder assembly**
        1524	500071	Rod locking cylinder	1
        1525	503911	Head sealing tube	1
        1526	503152	Bucket-locking cylinder	1
        1527	500061	Steering cylinder piston	1
        1528	500062**	Hydraulic cylinder sealing kit – quick-connect lock**	1
        1529	B101020423	Screw, 5/8 UNC×2-1/2, GR: Unbrako galvanized internal hex head screw	4
        1530	W21032	Washers, 5/8 hard flat galvanized	4
        1531	R10601060	Rolling pin, metric, M6, galvanized, 60mm long	1
        1532	501614	one-way valve	1
        1533	500062	Hydraulic cylinder sealing kit – quick-connect lock**
        1534	501626	shaft seal O-ring	1
        1535	501625	bezel	1
        1536	501624	bearing ring	3
        1537	501623	Piston seal	1
        1538	501622	Piston rod scraper	1
        1539	501621	Main seal	1
        1540	501620	bearing ring	1
        1541	501619	Piston seal O-ring	1
        1542	503052	Cab components
        1543	503234	Door	1
        1544	503235	Pin body	1
        1545	503236	Slide body	1
        1546	503237	plug	1
        1547	503238	hinge	2
        1548	503665	Hinge pin	2
        1549	503666	Bushing hinge
        1550	500100	Door buffer	5
        1551	B081016425	Screw, 1/2UNC×2 GR: Unbrako galvanized semi-circular head bolt	8
        1552	N081243	Nut, 1/2 UNC GR:5 Stainless Steel Nylon	8
        	W20832	Washer, 1/2 hard flat galvanized
        1553	B081012221	Screw, 1/2 UNC×1-1/2 GR:5 galvanized hexagonal head	8
        1554	W20822	Washers, 1/2 springs (galvanized)	2
        1555	N101223	Nuts, 5/8 UNC GR:8 galvanized nylon	2
        1556	W21032	Washers, 5/8 hard flat galvanized	2
        1557	C10322032	Cotter pin M3.2×32 length	2
        1558	504395	Transmission cover	2
        1559	504396	Top of the hose cover	1
        1560	504397	bottom of the hose cover	1
        	504377	armrest	1
        	B081004221	Screw, 1/4UNC x 1/2 GR:5 galvanized hexagonal head	1
        	W20422	Washers, 1/4 springs (galvanized)	2
        	503053	Roof Components	2
        	503202	Canopy frame	1
        	503203	Back canopy	1
        	B161040321	Screw, 1 UNC × 5 GR:8 galvanized hexagonal head	1
        	N161323	Nut, 1 UNC GR:8 galvanized nylon	1
        	B121032425	Screw, 3/4 UNC×2 GR: Unbrako galvanized semi-circular head bolt	2
        	N121321	Nuts, 3/4 UNC GR:8 galvanized standard	2
        	W21222	Washers, 3/4 springs, galvanized
        	504022	Deflector plate canopy	2
        	B122024321	Screw, 3/4 UNC×3 GR:8 galvanized	4
        	504308	foot ceiling	1
        	B121024221	Screw, 3/4 UNC×3 GR:5 galvanized hexagonal head	2
        	500033	Seating Components
        	500119	Driver’s seat	1
        	501577	seat belt	1
        	501662	Suspension – Driver’s Seat	1
        	501663	Shock absorbers – including #501662	1
        	501664	Height and angle – driver’s seat	1
        	501665	Seat Cushion Frame – Driver’s Seat	1
        	501666	Backrest Frame – Driver’s Seat	1
        	501667	Seat cushion – driver’s seat	1
        	501668	Sliding Kit – Driver’s Seat	1
        	501662**	Suspension – Driver’s Seat**
        	507517	Pivot pin – short	2
        	507558	Pivot pin – length	2
        	507559	Fixed bracket	3
        	507560	Connecting plate – bottom	1
        	507561	Weight adjustment lever	1
        	507562	stabilizer bar	1
        	507563	Connecting plate – upper part	1
        	507564	spring	2
        	507565	Adjustable spindle shaft	1
        	507566	Rolling pin	1
        	503055	Front frame protective plate assembly
        	503154	mudguard right side	1
        	503155	mudguard left side	1
        	503156	aileron	2
        	500199	Clamps, bottom, mudguard ailerons	2
        	500200	Clamp, side, mudguard aileron	2
        	500201	Clamp, bevel, mudguard aileron	2
        	B121018221	Screw, 3/4 UNC×2-4/1 GR:5 galvanized hexagonal head	12
        	N121223	Nuts, 3/4 UNC GR:5, galvanized nylon	12
        	W21222	Washers, 3/4 springs (galvanized)	12
        	B081016221	Screw, 1/2 UNC×2 GR:5 galvanized hexagonal head	22
        	N081213	Nut, 1/2 UNC GR:5 Black Nylon	22
        	W208125	Washers, 1/2 flat galvanized	22
        	505252	Pin rack	2
        	505253	Pin rack	2
        	505512	Clamp, top, mudguard aileron	2
        	B061011521	Screw, 3/8 UNC×1-3/8 GR:5 galvanized hexagonal head	8
        	N061523	Nuts, 3/8 UNC GR:5 galvanized nylon	8
        	W20612	Washers, 3/8 flat galvanized	8
        	503908	Steering contact connection component
        	500148	Flange-mounted bushing	4
        	500154	cover plate	1
        	500156	Pivot	1
        	500158	seal	4
        	500159	Flange-mounted bushing	1
        	500160	Flange-mounted bushing	1
        	500161	Pin, steering hinge	1
        	500162	Bearing support, steering hinge	1
        	500163	Clamping plate, steering hinge	1
        	500166	Steering hinge bearing	1
        	500093	Washers, hinge joints	2
        	BW04270409	Lubricating nozzle, 1/8, BSP, straight	2
        	502715	O-ring	1
        	508791	screw	6
        	W21032	Washers, 5/8 hard flat galvanized	6
        	B081010221	Screw, 1/2 UNC × 1-1/4 GR:5 galvanized hexagonal head	12
        	B061012311	Screw, 3/8 UNC×1-1/2 GR:8 hexagonal head	6
        	B061010222	Screw, 3/8 UNC×1-1/4 GR:5 galvanized hexagonal head thread to end	12
        	W20832	Washer, 1/2 hard flat galvanized	12
        	W20622	Washers, 3/8 galvanized springs	12
        	BW00289340	Safety lock wire, 1.25mm diameter	LM
        	500671	cover plate hinge point
        	506275	Cover component
        	506298	build	1
        	506299	build	1
        	506300	build	1
        	506301	build	1
        	506302	build	1
        	506303	build	1
        	506304	support	1
        	506305	support	1
        	506309	build	1
        	506313	build	1
        	506101	build	1
        	503192	skid plate – steering cylinder	1
        	504687	manifold cover	1
        	506310	support	4
        	506007	Radiator cover	2
        	506376	Protective plate	1
        	506315	build	1
        	506000	Power support – 1200 Newtons	5
        	506546	support	2
        	506552	Power support – 600 Newtons	2
        	504459	Grease line assembly – manual
        	500488	manifold, grease	3
        	DUDB15-0207	Fittings, pipe fittings 1/8 BSPT convex × 7/16 JIC convex	16
        	DUDB15-0407	Fittings, pipe fittings 1/4 BSPT convex × 7/16 JIC convex	16
        	DUD59-02	Connector, plug 1/8 BSPT steel	2
        	BW04270409	Grease nipple, 1/8, BSP, straight	18
        	D2800-04-40-7	Hose, grease 1/4×400×7/16 JIC
        	D2800-04-50-7	Hose, grease 1/4 × 500 × 7/16 JIC	3
        	D2800-04-80-7	Hose, grease 1/4×800×7/17 JIC	3
        	D2800-04-120-7	Hose, grease 1/4×1200×7/18 JIC	3
        	D2800-04-160-7	Hose, grease 1/4×1600×7/19 JIC	1
        	D2800-04-220-7	Hose, grease 1/4×2200×7/20 JIC	2
        	D2800-04-250-7	Hose, grease 1/4×2500×7/21 JIC	3
        	D2800-04-300-7	Hose, grease 1/4×3000×7/22 JIC	1
        	508560	Manifold, grease 2 holes	2
        		Section 7: Pneumatic System
        		Pneumatic starting, safety and auxiliary components
        	506688	respirator	2
        	501514	trumpet	1
        	501515	Isolation valve 1” bidirectional	1
        	501516	safety valve	1
        	501517	Coupling	1
        	501518	1″ Three-way ball valve 16	1
        	503637	gas tank	1
        	503715	Air compressor filter	1
        	501527	Neutral start valve	1
        	501528	Safety start valve	2
        	503931	Start and parking brake interlock valve	2
        	504796**	Start the motor**	1
        	503712	Close cylinder	1
        	501595	Gauge-Regulator Pressure	1
        	504300	Filter Water Separator	1
        	500435	Valve horn	1
        	500439	Valve roller cam 3/2	1
        	506646	Air compressor assembly	1
        	500437	Valve start	1
        	500433	air pressure gauge	1
        	500436	switch	1
        	500438	Valve parking brake	1
        	506135**	Pressure Regulator – 90PSI**	1
        	505765	Engine oil pressure gauge	1
        	506696	Inflation valve bracket	1
        	507659	Starter motor mounting bracket	1
        	501754	manifold body	2
        	507704	Twisted Hose – Air Compressor	1
        	503933	plunger	1
        	503932	Compatible parts	1
        	506135**	Pressure Regulator – 90PSI**
        	505934	pressure regulator	1
        	505933	pressure gauge	1
        	505932	support	1
        	507825	Hydraulic cover assembly
        	500103	Cover, hydraulic oil tank	1
        	500473	Sealing kit hydraulic oil tank	1
        	B061010221	Screw, 3/8 UNC×1-1/4 GR:5 galvanized hexagonal head	12
        	W20622	Washers, 3/8 galvanized springs	12
        		Section 8: Annexes and their annexes
        	506933	Quick-connect manual hairpin assembly
        	504853**	Quick Connect System Manual Fork Holder Assembly**	1
        	506041	Short spatula	2
        	506930	Nameplate spatula	1
        	504853**	Quick Connect System Manual Fork Holder Assembly**
        	504839	Manual spatula holder details	1
        	504851	Shovel positioning pin	2
        	500130	spade arm	1
        	500129	End cap shovel fork arm	2
        	B081008423	Screw, 1/2 UNC×1 GR: Unbrako galvanized hex head screw	4
